MPLS Guide MPLS and RSVP-TE
3HE 18686 AAAB TQZZA © 2022 Nokia.
Use subject to Terms available at: www.nokia.com
277
Output Example
A: ALU-12# show router rsvp interface “ip-10.10.1.1” detail
===============================================================================
RSVP Interfaces (Detailed): ip-10.10.1.1
-------------------------------------------------------------------------------
Interface : ip-10.10.1.1
-------------------------------------------------------------------------------
Interface : ip-10.10.1.1
Port ID : 1/1/1
Admin State : Up Oper State : Up
Active Sessions : 0 Active Resvs : 0
Total Sessions : 0
Subscription : 10 % Port Speed : 1000 Mbps
Total BW : 100 Mbps Aggregate : Dsabl
Hello Interval : 3000 ms Hello Timeouts : 0
Key Type Auth : Disabled
Keychain Auth : Disabled
Auth Rx Seq Num : n/a Auth Key Id : n/a
Auth Tx Seq Num : n/a Auth Win Size : n/a
Refresh Reduc. : Disabled Reliable Deli. : Disabled
Bfd Enabled : No Graceful Shut. : Disabled
ImplicitNullLabel : Disabled* GR helper : Disabled
IGP Update
Table 25 Router RSVP-TE Interface Field Descriptions
Label Description
Interface The name of the IP interface
Total Sessions The total number of RSVP-TE sessions on this interface. This
count includes sessions that are active as well as sessions that
have been signaled but a response has not yet been received.
Active Sessions The total number of active RSVP-TE sessions on this interface
Total BW (Mbps) The amount of bandwidth in megabits per second (Mbps)
available to be reserved for the RSVP-TE protocol on the
interface
Resv BW (Mbps) The amount of bandwidth in megabits per second (Mbps)
reserved on this interface. A value of zero (0) indicates that no
bandwidth is reserved.
Adm Down — the RSVP-TE interface is administratively disabled
Up — the RSVP-TE interface is administratively enabled
Opr Down — the RSVP-TE interface is operationally down
Up — the RSVP-TE interface is operationally up
Interfaces The number of interfaces listed in the display
