bypass-tunnel
Syntax bypass-tunnel [to ip-address] [protected-lsp [lsp-name]] [dynamic | manual] [detail]
Context show>router>mpls
Description If fast reroute is enabled on an LSP and the facility method is selected, instead of creating a
separate LSP for every LSP that is to be backed up, a single LSP is created that serves as a
backup for a set of LSPs. This type of LSP tunnel is called a bypass tunnel.
Parameters ip-address — specifies the IP address of the egress router
lsp-name — specifies the name of the LSP protected by the bypass tunnel
dynamic — displays dynamically assigned labels for bypass protection
manual — displays manually assigned labels for bypass protection
detail — displays detailed information
Output The following output is an example of MPLS bypass tunnel information, and Table 10
describes the fields.
Output Example
A:ALU-12>show>router>mpls# bypass-tunnel to 10.20.1.4
===============================================================================
Legend : m - Manual d - Dynamic
===============================================================================
To State Out I/F Out Label Reserved Protected Type
BW (Kbps) LSP Count
-------------------------------------------------------------------------------
10.20.1.4 Up lag *-* 131071 0
-------------------------------------------------------------------------------
Bypass Tunnels : 1
===============================================================================
A:ALU-12>show>router>mpls#
Table 10 Router MPLS Bypass-Tunnel Field Descriptions
Label Description
To The system IP address of the egress router
State The administrative state of the LSP
Out I/F The name of the network IP interface
Out Label The incoming MPLS label on which to match
Reserved BW (Kbps) The amount of bandwidth in kilobytes per second (Kbps)
reserved for the LSP
Protected LSP Count The number of times this LSP has used a protected LSP
