MPLS and RSVP-TE
286
MPLS Guide
© 2022 Nokia.
Use subject to Terms available at: www.nokia.com
3HE 18686 AAAB TQZZA
Table 31 Router RSVP-TE Status Field Descriptions
Label Description
Admin Status Down — RSVP-TE is administratively disabled
Up — RSVP-TE is administratively enabled
Oper Status Down — RSVP-TE is operationally down
Up — RSVP-TE is operationally up
Keep Multiplier The keep-multiplier number used by RSVP-TE to declare that
a reservation is down or the neighbor is down
Refresh Time The refresh-time interval, in seconds, between the successive
PATH and RESV refresh messages
Message Pacing Enabled — RSVP-TE messages, specified in the max-burst
command, are sent in a configured interval, specified in the
period command
Disabled — message pacing is disabled. RSVP-TE message
transmission is not regulated.
Pacing Period The time interval, in milliseconds, during which the router can
send the number of RSVP-TE messages specified in the max-
burst command
Max Packet Burst The maximum number of RSVP-TE messages that are sent
under normal operating conditions in the period specified
Refresh Bypass Enabled — the refresh-reduction-over-bypass command is
enabled
Disabled — the refresh-reduction-over-bypass command is
disabled
Rapid Retransmit The time interval for the rapid retransmission time, which is
used in the retransmission mechanism that handles
unacknowledged message_id objects (the units “hmsec”
represent hundreds of msec; for example, 5 hmsec represents
500 msec)
Rapid Retry Limit The value of the rapid retry limit, which is used in the
retransmission mechanism that handles unacknowledged
message_id objects
Graceful Shutdown Specifies whether graceful shutdown of the RSVP node is
enabled
