MPLS Guide MPLS and RSVP-TE
3HE 18686 AAAB TQZZA © 2022 Nokia.
Use subject to Terms available at: www.nokia.com
241
LSP Index The LSP index value
TTM Tunnel Id The Tunnel Table Manager tunnel identifier
From The IP address of the ingress router for the LSP
To The system IP address of the egress router for the LSP
Adm State Down — the path is administratively disabled
Up — the path is administratively enabled
Oper State Down — the path is operationally down
Up — the path is operationally up
LSP Up Time The length of time that the LSP has been operational
LSP Down Time The total time that the LSP has not been operational
Transitions The number of transitions that have occurred for the LSP
Path Changes The number of path changes this LSP has had. For every path
change (path down, path up, path change), a corresponding
syslog/trap (if enabled) is generated.
Retry Limit The number of attempts that the software should make to re-
establish the LSP after it has failed
Retry Timer The time, in seconds, for LSP re-establishment attempts after an
LSP failure
Signaling The signaling style
Style SE (shared explicit) — specifies a shared reservation
environment with a limited reservation scope. This reservation
style creates a single reservation over a link that is shared by an
explicit list of senders.
FF (fixed filter) — specifies a dedicated reservation environment
with an explicit reservation scope. This reservation style specifies
an explicit list of senders and a distinct reservation for each of
them.
Hop Limit The maximum number of hops that an LSP can traverse,
including the ingress and egress routers
MTU The size of the maximum transmission unit (MTU) that is
negotiated during establishment of the LSP
Adaptive Indicates whether the make-before-break option is enabled or
disabled for resignaled paths
Table 13 MPLS LSP Detailed Field Descriptions (Continued)
Label Description
