ClassType The class type value
FastReroute Enabled — fast reroute is enabled. In the event of a failure, traffic
is immediately rerouted on the precomputed protection LSP, thus
minimizing packet loss.
Disabled — there is no protection LSP from each node on the
primary path
Oper FR Indicates whether FRR has been enabled or disabled
CSPF Indicates whether CSPF has been enabled or disabled
ADSPEC Enabled — the LSP will include advertising data (ADSPEC)
objects in RSVP-TE messages
Disabled — the LSP will not include advertising data (ADSPEC)
objects in RSVP-TE messages
Metric The TE metric value
Load Bal Wt The load balancing weight value
Include Grps The admin groups that are to be included by an LSP when
signaling a path
Exclude Grps The admin groups that are to be avoided by an LSP when
signaling a path
Least Fill Indicates whether the least fill option is enabled or disabled
Entropy Label Indicates whether the entropy label capability is enabled or
disabled
Oper Entropy Label Indicates whether the entropy label capability is operational or
not operational
Negotiated EL Indicates whether the negotiated entropy label capability is
enabled or disabled
Auto BW Indicates whether auto-bandwidth adjustment is enabled or
disabled
LdpOverRsvp Indicates whether LDP over RSVP tunneling is enabled or
disabled
VprnAutoBind Indicates whether VPRN auto-bind tunneling is enabled or
disabled
IGP Shortcut Indicates whether the IGP shortcut option is enabled or disabled
Table 13 MPLS LSP Detailed Field Descriptions (Continued)
Label Description
