MPLS Guide MPLS and RSVP-TE
3HE 18686 AAAB TQZZA © 2022 Nokia.
Use subject to Terms available at: www.nokia.com
243
Output Example
*A:ALU-48# show router mpls lsp path detail
===============================================================================
MPLS LSP Path (Detail)
===============================================================================
Legend :
@ - Detour Available # - Detour In Use
b - Bandwidth Protected n - Node Protected
===============================================================================
LSP 1 Path 1
-------------------------------------------------------------------------------
LSP Name : 1 Path LSP ID : 30226
From : 10.20.1.1 To : 10.20.1.2
Adm State : Up Oper State : Up
Path Name : 1 Path Type : Primary
Path Admin : Up Path Oper : Up
OutInterface: 1/1/1 Out Label : 131071
Path Up Time: 0d 00:59:39 Path Dn Time: 0d 00:00:00
Retry Limit : 20 Retry Timer : 30 sec
RetryAttempt: 0 Next Retry *: 0 sec
Bandwidth : 200 Mbps Oper Bandwi*: 50 Mbps
Hop Limit : 255
IGP LFA Indicates whether the IGP Loop-Free Alternate option is enabled
or disabled
IGP Rel Metric Indicates whether the IGP relative metric option is enabled or
disabled
BGPTransTun Indicates whether the BGP transport tunnel option is enabled or
disabled
Oper Metric The LSP operational metric value
Prop Adm Grp Indicates whether the propagate administrative group option is
enabled or disabled
PCE Report Specifies the PCE reporting mode, either enabled, disabled, or
inherited
PCE Compute Indicates whether the PCE computation option is enabled or
disabled
PCE Control Indicates whether the PCE control option is enabled or disabled
Primary (a) The preferred path for the LSP
Up Time The length of time that the path has been up
Bandwidth The amount of bandwidth in megabits per second (Mbps)
reserved for the LSP path
Table 13 MPLS LSP Detailed Field Descriptions (Continued)
Label Description
