Table 43 LDP Discovery Field Descriptions
Label Description
Interface Name The name of the interface
Local Addr The IP address of the originating (local) router
Peer Addr The IP address of the peer
Adj Type The adjacency type between the LDP peer and LDP session
State Established — indicates that the adjacency is established
Trying — indicates that the adjacency is not yet established
No. of Hello
Adjacencies
The total number of hello adjacencies discovered
Up Time The amount of time the adjacency has been enabled
Hold-Time
Remaining
The time left before a neighbor is declared to be down
Hello Mesg Recv The number of Hello messages received for this adjacency
Hello Mesg Sent The number of Hello messages that have been sent for this
adjacency
Remote Cfg Seq
No
The configuration sequence number that was in the Hello message
received when this adjacency started up. This configuration
sequence number changes when there is a change of configuration.
Remote IP
Address
The IP address used on the remote end for the LDP session
Local Cfg Seq No The configuration sequence number that was used in the Hello
message sent when this adjacency started up. This configuration
sequence number changes when there is a change of configuration.
Local IPv4
Address
Local IPv6
Address
The IP address used locally for the LDP session
