Nokia 7705 SAR-W Series User Manual

MPLS Guide Label Distribution Protocol
3HE 18686 AAAB TQZZA © 2022 Nokia.
Use subject to Terms available at: www.nokia.com
487
10.1.0.8/32 Pop n/a -- -- 0
10.1.0.9/32 Pop n/a -- -- 0
...
10.251.0.0/16 Pop n/a -- -- 0
10.252.0.0/16 Pop n/a -- -- 0
10.253.0.0/16 Pop n/a -- -- 0
10.254.0.0/16 Pop n/a -- -- 0
-------------------------------------------------------------------------------
No. of FECs: 508
===============================================================================
===============================================================================
LDP IPv6 Static Prefix FECs
===============================================================================
Prefix NHType NextHop IngLabel EgrLabel OperIngLabel
-------------------------------------------------------------------------------
No Matching Entries Found
===============================================================================
*A:ALU-12#
Table 44 FEC-Originate Field Descriptions
Label Description
Prefix The static prefix FEC
NHType The type of next hop for this entry:
Unknown: the next-hop type has not been set
IP Addr: the next hop is an IP address
Pop: there is no next hop; label is popped and packet routed
Unnumbered: the next hop is an unnumbered interface
Next Hop The IP address of the next hop, or Unnumbered for unnumbered
interfaces
IngLabel The label that is advertised to the upstream peer. If this variable
is set to the default value of 4294967295, the ingress label will be
dynamically assigned by the label manager.
EgrLabel The egress label associated with this next-hop entry. The LSR
will swap the incoming label with the configured egress label. If
this egress label has a value of 4294967295, the LSR will pop the
incoming label.
OperIngLabel The actual or operational value of the label that was advertised
to the upstream peer
