Nokia 7705 SAR-W Series User Manual

MPLS Guide Label Distribution Protocol
3HE 18686 AAAB TQZZA © 2022 Nokia.
Use subject to Terms available at: www.nokia.com
507
Table 50 LDP Bindings Field Descriptions
Label Description
Legend U: Label In Use
N: Label Not In Use
W: Label Withdrawn
S: Status Signaled Up
D: Status Signaled Down
E: Epipe Service
V: VPLS Service
M: Mirror Service
A: Apipe Service
F: Fpipe Service
I: IES Service
R: VPRN service
P: Ipipe Service
WP: Label Withdraw Pending
C: Cpipe Service
BU: Alternate for Fast Re-Route
TLV: (Type, Length: Value)
H: Hpipe
LF: Lower FEC
UF: Upper FEC
Type The service type exchanging labels in the SDP. The possible
types displayed are Epipe, Spoke, and Unknown.
VCId The value used by each end of an SDP tunnel to identify the VC
SvcID Identifies the service in the service domain
SDPId Identifies the SDP in the service domain
Peer The IP address of the peer
IngLbl The ingress LDP label
U — indicates that the label is in use
R — indicates that the label has been released
EgrLbl The egress LDP label
LMTU The local MTU value
RMTU The remote MTU value
No. of Prefix Bindings The total number of LDP bindings on the router
EgrIntf/LspId The egress interface LSP ID
EgrNextHop The egress next-hop address, or Unnumbered for unnumbered
interfaces
AGI Type The address group identifier (AGI)
SAII Peer The source attachment individual identifier (SAII)
TAII EgrLbl The target attachment individual identifier (TAII)
Prefix The FEC address
