11. Module reference: Envelope group NORD MODULAR G2 V1.1

Page 144

S(S(

)

))

)

Sets the sustain level. This level will be held (sustained) for as long as the logic Gate signal is

high. When the logic Gate signal drops to zero, the envelope will proceed with the release

stage. The sustain level is displayed in ‘units’ in the corresponding display box. Range: 0 to

64 units

H(H(

Sets the time the envelope should remain at maximum level. The hold time is displayed in

milliseconds or seconds in the corresponding display box. Range: 0.5 ms to 45 s.

R(R(

)

))

)

Sets the release time. When the logic Gate signal drops to zero, the envelope will decrease

from the sustain level to zero with the release time. The release is exponential (or selectable

between exponential and linear in some modules). The release time is displayed in millisec-

onds or seconds in the corresponding display box. Range: 0.5 ms to 45 s.

/D/D

/S/S

/H/H

/R/R

Some Envelope Generators feature control signal inputs for modulating the envelope seg-

ments. You can adjust the level of each control signal by turning the corresponding rotary

knob of [Attenuator Type I]. Note that the A, D, H and R control inputs handles bipolar

control signals. Positive control signals shortens the times and negative control signals in-

crease the times. With the H parameter it is the other way around.

All Envelope Generator modules features a graph which displays the envelope shape.

Any sustain level is indicated with an orange line; the rest of the envelope segments are

green. There is also a yellow horizontal line which indicates the zero level of the enve-

lope.
