11. Module reference: Delay group NORD MODULAR G2 V1.1

Page 194

An 8-tap delay with selectable time con-

trol between the taps. Note that the 8

taps are “in sequence”, i.e. between the

input signal and the first tap, the delay

corresponds to the displayed time. Then,

it takes twice this time for the second tap to output the signal and three times the set delay time for the

third tap to output the signal, and so on. In this module, the displayed Range setting refers to the total

time between the input signal and the last tap (output 8) and with the Time knob you set the delay time

between adjacent taps. See also "Common Delay group parameters”.

The Delay Shift Register basically works

like a Sample & Hold module, with the

difference that for every new sample, it

shifts the previous sample one step to the right among the eight outputs. This can be useful for “storing”

keyboard Note data, for example. See also "Common Delay group parameters”.

The Clocked Delay Register basically

works like the Delay Shift Register above

but with only one output. With the Sam-

ple Delay knob you set how many Clock pulses is required to output the sampled value. For example, if

you have set the Sample Delay to 72, the value will be output 72 Clock pulses later. See also "Common

Delay group parameters”.

This is a single channel audio delay with

Feedback and Filter controls. You can

also set the mix between delayed signal

and input signal with the Dry/Wet knob.
