Parts
7-6
Part 1120277_01
E 2012 Nordson Corporation
Hopper/Melt Plate Assembly Parts
SeeFigure7-3.
Item Part Description Quantity Note
— ------ HOPPER,GRID ASSY,133MM,PB4,HO —
1 ------ S HOPPER, WELDMENT, 133 ID, PB4 1
2 ------ S PLATE,SLUG MELTER,PB4,HO 1
3 ------ S COVER, ELECT, MELT PLATE, PB4 1
4 1100759 S INSULATOR, 134 ID, ALTA TT-RM 1
5 ------ S SCR,SKT,M5X10,BL 9
6 ------ S SCR,SKT,M4X8,BL 6
7 ------ S WASHER,FLT,M,NARROW,M4,STL,ZN 5
8 ------ S SCR,SKT,M6X20,BL 8
9 ------ S SCR,SKT,M6X60,BL 4
10 ------ S PLATE, CAPTURE, RTD, ALTA TT-RM 1
11 ------ S NUT,PANEL MOUNTING 1
12 ------ S WASHER,LK,M,EXT,M10,ZN 1
13 900344 S LUBRICANT,NEVER SEEZ,8OZ CAN 1
14 ------ S BLOCK, CLAMP, HOPPER , PB4 1
15 ------ S STAND-OFF, 13 DIA X 70 LONG, M6 4
16 ------ S SCR,SKT,M6X35,B 4
17 ------ S CABLETIE,4 IN,338F/170C,BLUE 4
NS 1120261 KIT,SERVICE,GRID HEATER ASSY,240V,PB4,
HO
1 A
NS 1096020 KIT,SERVICE,MAN./GRID,RTD SENSOR, PB4 1 A
NOTE A: Refer to Heaters and RTDs (Sensors) later in t his section for an illustration of the heater/RTD locations.
NS: Not Shown
