How to Operate the Control Panel with a Non-Alarm
30 AFC-600 Operations PN 51033:A 3/8/99
+RZWKH&RQWURO3DQHO,QGLFDWHVDQ$FWLYH)LUH&RQWURO
Activation of a
FIRE CONTROL
point causes the control panel to do the following:
• Produce a pulsed audible tone
• Turn on the Trouble relay (MPS-6, TB5)
• Activate the monitor module Control-by-Event
• Flash the
SYSTEM TROUBLE
LED
• Send a message to the LCD display, History buffer, and installed printers, terminal
mode LCD-80s, and CRT-2s
• Display an
ACTIVE
status banner and
FIRE CONTROL
Type Code on the LCD
display, along with information specific to the device, as shown in Figure 23
)LJXUH  6DPSOH )LUH &RQWURO 3RLQW 'LVSOD\
+RZWKH&RQWURO3DQHO,QGLFDWHVDQ$FWLYH1RQ)LUH3RLQW
Non-Fire point operation does not affect control panel operation. Activation of a
Non-Fire point activates CBE—but does not cause any indication on the control panel.
For example, you can program a Non-Fire point to turn lights in a zone to a lower
setting when activated. In this case, when the point activates the control panel activates
the point’s CBE to turn the lights down without any audio or visual indication on the
control panel.
$&7,9( ),5( &21752/ 02'8/( $''5(66 0
=21(  30  0
6WDWXV EDQQHU $&7,9(
7
\S
H &RGH
),5( &21752/
=RQH DIIHFWHG E
\
WKH )LUH &RQWURO
