 9RLFH $ODUP 6
\
VWHPV
ATG-2 Audio Tone Generator
60 AFC-600 Operations PN 51033:A 3/8/99
$7*$XGLR7RQH*HQHUDWRU
$7*2YHUYLHZ
The ATG-2 provides user-selected tones for single or dual channel output. The ATG-2
provides several ways to page.
Direct paging The ATG-2 microphone with a button switch lets you page through
EVAC
CHANNEL
(primary) and
ALERT
CHANNEL
(secondary) speaker circuits. If
used with an optional FFT-7, the ATG-2 also lets you page through the system
from telephones installed throughout the installation.
1RWH
)RU PRUH LQIRUPDWLRQ RQ
$7* FRQIL
J
XUDWLRQ UHIHU WR
WKH 9RLFH 0RGXOHV 6HFWLRQ RI
WKH $)& ,QVWDOODWLRQ
0DQXDO
Remote paging microphone You can also set up the ATG-2 to pass-through an
audio message or tone received from another AMG-1 or ATG-2. In this
configuration, the ATG-2 serves as an alternate (remote) paging location for the
AMG-1 or main ATG-2. The ATG-2 provides override paging capabilities from the
ATG-2 microphone. All communications go through NAC 1 using ACS mode
connected to the control panel unless set up for remote paging microphone
operation. For instructions on ACS mode, refer to the AFC-600 Installation
Manual.
Figure 66 shows the operating features of the ATG-2:
)LJXUH  2SHUDWLQJ )HDWXUHV RI WKH $7*
Table 24 contains descriptions of the four LEDs:
7DEOH $7* /('V
0LFUR
S
KRQH
3$*( 6(/(&7
VZLWFK ² OHWV
\
RX
S
D
J
H WKURX
J
K
V
S
HDNHU FLUFXLWV RQ RQH WZR RU ERWK FKDQQHOV
6
\
VWHP 6WDWXV
,QGLFDWRU /('V
0LFUR
S
KRQH
6ZLWFK
LED Color Lights to show
ON
LINE
LED green The ATG-2 is properly connected to the control
panel.
EVAC
CHANNEL
green Paging will take place over the
EVAC
CHANNEL
(primary). Produces a slow whoop, Hi/Lo, or steady
tone.
ALERT
CHANNEL
green Paging will take place over the
ALERT
CHANNEL
(secondary). Produces a chime or a
20 pulses-per-minute tone.
TROUBLE
LED yellow A trouble in local audio subsystem equipment
(AMG-1, AA-30, FFT-7).
