Presignal and Positive Alarm Sequence (PAS) Operation
78 AFC-600 Operations PN 51033:A 3/8/99
3UHVLJQDODQG3RVLWLYH$ODUP6HTXHQFH3$62SHUDWLRQ
2YHUYLHZ
This section describes the Presignal and PAS selection, how to do the following:
• View Presignal and PAS selections,
• Respond to an alarm with Presignal
• Operate the control panel with a Presignal Delay Timer only
• Operate the control panel with a Presignal Delay Timer and PAS
:KDWLV3UHVL
QDODQG3$6"
Presignal is a feature that initially causes alarm signals to only sound in specific areas,
monitored by qualified persons, where activating a general alarm requires human
verification. This allows delay of the alarm up to 180 seconds after the start of alarm
processing. The control panel Presignal feature provides two selections:
1RWH
3UHVL
QDO GLIIHUV IURP WKH
$ODUP 9HULILFDWLRQ 7LPHU ZKLFK
GRHV QRW UH
XLUH KXPDQ
LQWHUYHQWLRQ
• A
Presignal Delay Timer
(60-180 seconds) that delays activation of all outputs
with a CBE that includes Special Zone F0.
• A
PAS
selection, in addition to the
Presignal Delay Timer
, that allows a
15-second time period for acknowledging an alarm signal from a fire detection/
initiating device. If the alarm is not acknowledged within 15 seconds, all local and
remote outputs activate immediately and automatically.
Figure 80 contains an illustration of Presignal and PAS timing.
)LJXUH 3UHVLJQDO DQG 3$6 7LPH
Continued on the next page...
3UHVL
QDO 'HOD
7LPHU V
3$6 V
,QLWLDO DODUP
DQQXQFLDWLRQ
$ODUP DFWLYDWHV RXW
XWV LI
DQHO LV QRW UHVHW
,I 3$6 < DODUP DFWLYDWHV
RXW
XWV LI QRW DFNQRZOHG
HG
