3-32
CHAPTER 3 REPAIR PROCEDURES
Figure 3-32. LCD Assembly Bulb Replacement.
BULB
END CAP
DIFFUSER PANEL
BRACKET
LCD ASSEMBLY
PLASTIC PUSH IN FASTENER
BULB WIRE
