Omron F3SJ-A series User Manual

89
F3SJ-A
User’s Manual
Chapter3 Wiring
Wiring/Installation
E
Internal wiring diagram (F39-JCB-L, F39-JCB-D)
If the length of the F39-JCA cable with connector on one end is insufficient, use 1 or more F39-
JCB cable with connectors on both ends to extend the length, as required.
Connection example
 Cable with Connectors on Both Ends: Cable for Connection with G9SA-300-SC (F39-
JCC, sold separately)
Set model name
*1
*1. Use only 1 set of F39-JCC. If the cable length is insufficient, use F39-JCB for extension so that F39-JCC should be on
the side of G9SA-300-SC.
For emitter For receiver L (mm)
F39-JCR2C F39-JCR2C-L Grey cable F39-JCR2C-D Black cable 200
F39-JC1C F39-JC1C-L F39-JC1C-D 1000
F39-JC3C F39-JC3C-L F39-JC3C-D 3000
F39-JC7C F39-JC7C-L F39-JC7C-D 7000
F39-JC10C F39-JC10C-L F39-JC10C-D 10000
F39-JC15C F39-JC15C-L F39-JC15C-D 15000
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
White
Brown
Green
Yellow
Grey
Pink
Blue
Red
Shield
Female
Connected to single-end connector cable, Cable
with connectors on both ends, Controller F3SP-B1P
White
Brown
Green
Yellow
Grey
Pink
Blue
Red
Shield
Male
Twisted pair wires are white and red, brown and blue, green and yellow, and grey and pink
Connected to connection cable and
Cable with connectors on both ends
Emitter
Receiver
Cable is grey
Cable is black
Model F39-JC
A-D(Black)
Model F39-JC B-L(Grey)
Model F39-JC A-L(Grey)
Cable with connectors on both ends
Model F39-JC
Cable with connector on one end
Model F39-JC A
Model F39-JC B-D(Black)
M12
39.5 L
43
(Unit: mm)
Body color: Grey
Body color: Grey
M12 Waterproof connector
M12 Waterproof connector
Insulated vinyl round cable dia. 6.6, shielded
8-wire (4-pair) (Cross section of conductor: 0.3mm
2
/ Insulator diameter: 1.15mm)
dia. 15 dia. 15
