Omron F3SJ-A series - Page 85

67
F3SJ-A
User’s Manual
Chapter3 Dimensions
Wiring/Installation
E
Dimensions A to C
A C + 109
BC + 66
C 4-digit number of the model name (protective height)
F39-LJ4
4-M5
B
19(*1)
19
66
37
A B
21.5
(21.5)
30
35
34
5
4
10
5
30
2
45
Side mounting
Use standard
brackets
C (Protective height)
(Unit: mm)
Material: Stainless steel
*1 A mounting width of 18 to 20 can be
supported when mounting with M5 screws.
