72
Chapter3 Dimensions
F3SJ-A
User’s Manual
Wiring/Installation
F39-LJ8 Space-saving Mounting Bracket
Brackets that can save mounting space for top and bottom
Dimensions A to C
The F39-LJ8 and intermediate mounting brackets cannot be mounted simultaneously, so set the protective height to
600mm or less.
AC + 23
B C - 10.3
C 4-digit number of the model name (protective height)
F39-LJ8
Backside mounting
Use standard
brackets
C (Protective height)
(Unit: mm)
Material: Stainless steel
11.5
33
2
25.65
8
16.65
B16.65
30
20
5.5
5.5
7
A
20
4-M5
B
Courtesy of CMA/Flodyne/Hydradyne ▪ Motion Control ▪ Hydraulic ▪ Pneumatic ▪ Electrical ▪ Mechanical ▪ (800) 426-5480 ▪ www.cmafh.com
