Omron F3SJ-A series - Page 91

73
F3SJ-A
User’s Manual
Chapter3 Dimensions
Wiring/Installation
E
 F39-LJ11 Top/bottom Mounting Bracket C
Dimensions A to C
A C + 109
BC + 69
C 4-digit number of the model name (protective height)
Use standard
brackets
26
㧔20㧕
13
㧔54.5㧕
34
3
13
30
6
20
54.5
ABB
2
1
4-M5
Hole size for mounting
4-Mounting holes
Material: Stainless steel
(Unit: mm)
C (Protective height)
