Menu Tables
FQ2 User’s Manual
417
Appendices
12
I/O setting
Output data setting
Noprotocol data output
Output data set --- Data 0 to data 31 --- p. 352,
p. 353.
p. 355
[MENU]
Data settings Sets data to output to selected data num-
ber.
Text strings for the filter items, position
compensation items, inspection items
and expression that are set
---
Multi-data
setting
---
Rename Changes the name of the selected data
number.
The name can be changed to a name
with up to 15 alphanumeric characters.
---
Copy Copies the contents registered in the
selected data number to another data
number.
---
Delete Clears the content of the selected data
number.
---
Output form --- --- --- p. 333
Output form Selects the format of the data to be out-
put.
ASCII (default) or Binary Scene p. 355
When output format is ASCII
Digits of inte-
ger
Sets the digits of the integer part,
including the sign. However, + is not out-
put for positive numbers.
Example: Setting 4-digit data: −5963 is
output as -999.
1 to 10 (Default: 6) Scene
Digits of dec-
imal
Sets the output digits for the decimal
part. If it is set to 0, the decimal part is
rounded off before the data is output.
0 to 4 (default: 4) Scene
Negative Selects what to display as the sign when
the number is negative.
− (Default) or 8 Scene
0 suppress Selects the method to adjust unused dig-
its on the left in output data.
ON: Zeros are inserted for unused digits.
OFF: Spaces are inserted for unused
digits.
Example:
The following examples are for when five
integer digits and three decimal digits are
set and the data is 100.000.
ON: 00100.000
OFF: _100.000 (The underscore indi-
cates a space.)
ON or OFF (default) Scene
Menu command Description Setting range Data Refer-
ence
To Next Page
