Adjusting the Images That Were Taken
86
FQ2 User’s Manual
4 Press [OK].
5 Press [Back].
• Detailed Settings for Edge Rotation Position Compensation
The settings for the Edge Rotation Position Compensation item are almost the same as those for the Edge
Position inspection item.
Make the settings in the same way as for the Edge Position inspection item. ( 4-7 Inspecting with the
Edge Position Inspection Item: p. 120)
However, the following settings are included only in the Edge Position Compensation Item.
• Teaching
• Measurement Regions and Measurement Directions
Set the measurement regions and measurement directions for both edge 0 and edge 1.
[Image] − [Image adjustment] − [Edge rot. pos. Comp.] − [Modify] − [Basic] − [Teach]
The settings are the same as those for the Two-edge Position Compensation item.
Teaching: p. 82
• Reference Angle
Set the reference angle.
Press [ ]
− [Edit Ref. angle] on the right of the display and set the angle.
• Source Image
You can select the image to which to apply the results of position compensation processing.
Applying the Results of Position Compensation: p. 75
• Interpolation
You can select the precision of position compensation.
If you select [Bilinear], the precision of position compensation will increase.
[Image] − [Image adjustment] − [2Edge position comp.] − [Modify] − [Details] − [Interpolation]
The settings are the same as those for the Shape Search Position Compensation item.
Interpolation: p. 77
• Measurement Data That Can Be Used for External Outputs and Calculations
The following values can be used as measurement data and output to external devices via Ethernet or used in
calculations.
Expression text string Data name Description Data range
JG Judgement This is the judgement result. −2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG
DT Scroll θ This is the amount of position compensa-
tion.
−180 to 180
X0 Edge 0 position X This is the X coordinate of the measured
edge 0 position.
−99,999.9999 to 99,999.9999
