Safety function selector switch
ON OFF
Wiring Example
M
X
+24V
SF2
3G3M1
24V
SF1
DIC
DOC
DO1
o
r
DO2
EDM
In the factory default state, operation is always enabled by the short-circuit bars as shown in the figure
above.
For details on connection with safety devices, refer to 7-6 Safety Function on page 7-69.
2 Design
2-59
M1 Series Standard Type User's Manual (I669)
2-3 Wiring
2
2-3-8 Safety Function

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
