Ease of Use
This inverter is also designed for ease of use in terms of the parameter settings, protection, and oper-
ations.
This contributes to the reduction of man-hours in inverter-related work.
Password Function
This inverter has the password protection function to prevent unauthorized reading and changing of
parameters.
Initial screen automatic return function of the Operator
You can register the initial screen (data etc.) to display on its Operator.
After operating the Digital Operator for adjustment or inverter monitoring, the screen will return to
the initial screen unless you operate any key for five minutes.
Simplified parameter setting by user parameters
Any parameters can be registered as user parameters.
It is possible to display only the registered parameters to improve the operability of equipment.
1-1-2
Classes of 3G3M1 Series Inverter
There are three voltage classes for 3G3M1 Series Inverters: 200-V class supporting single-phase 200
V
AC and three-phase 200 VAC, and 400-V class supporting three-phase 400 V
AC.
The maximum applicable motor capacity for this inverter is 0.1 to 22 kW for the heavy load mode and
0.2 to 30 kW for the light load mode.
All models comply as standard with the EC Directives and UL/cUL Standards.
Rated voltage Enclosure rating
Maximum applicable motor ca-
pacity
Model
HHD: Heavy
load
HND: Light
load
Three-phase 200 VAC IP20 0.1 kW 0.2 kW 3G3M1-A2001
0.2 kW 0.4 kW 3G3M1-A2002
0.4 kW 0.75 kW 3G3M1-A2004
0.75 kW 1.1 kW 3G3M1-A2007
1.5 kW 2.2 kW 3G3M1-A2015
2.2 kW 3.0 kW 3G3M1-A2022
3.7 kW 5.5 kW 3G3M1-A2037
5.5 kW 7.5 kW 3G3M1-A2055
7.5 kW 11 kW 3G3M1-A2075
11 kW 15 kW 3G3M1-A2110
15 kW 18.5 kW 3G3M1-A2150
18.5 kW 22 kW 3G3M1-A2185
1 Overview
1-4
M1 Series Standard Type User's Manual (I669)
