Omron M1 Series User Manual

Rated voltage Enclosure rating
Maximum applicable motor ca-
pacity
Model
HHD: Heavy
load
HND: Light
load
Three-phase 400 VAC IP20 0.4 kW 0.75 kW 3G3M1-A4004
0.75 kW 1.1 kW 3G3M1-A4007
1.5 kW 2.2 kW 3G3M1-A4015
2.2 kW 3.0 kW 3G3M1-A4022
3.0 kW 4.0 kW 3G3M1-A4030
4.0 kW 5.5 kW 3G3M1-A4040
5.5 kW 7.5 kW 3G3M1-A4055
7.5 kW 11 kW 3G3M1-A4075
11 kW 15 kW 3G3M1-A4110
15 kW 18.5 kW 3G3M1-A4150
18.5 kW 22 kW 3G3M1-A4185
22 kW 30 kW 3G3M1-A4220
Single-phase 200 VAC IP20 0.1 kW 0.2 kW 3G3M1-AB001
0.2 kW 0.4 kW 3G3M1-AB002
0.4 kW 0.55 kW 3G3M1-AB004
0.75 kW 1.1 kW 3G3M1-AB007
1.5 kW 2.0 kW 3G3M1-AB015
2.2 kW 2.7 kW 3G3M1-AB022
3.7 kW - 3G3M1-AB037
1 Overview
1-5
M1 Series Standard Type User's Manual (I669)
1-1 Overview of Functions
1
1-1-2 Classes of 3G3M1 Series Inverter

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
