Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
d297
Current Reference Po-
sition Monitor (LSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
page
6-57
d298
Current Feedback Po-
sition Monitor (MSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
page
6-57
d299
Current Feedback Po-
sition Monitor (LSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
page
6-57
4-2-11
Parameter y (RS-485 Communication Settings)
Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
y11
RS-485 Communica-
tion Station No. Selec-
tion
1 to 255
1 - -
page
8-5
y12
Operation Selection
on Communication Er-
ror
0: Immediately trip with alarm
ErP
1: Trip with alarm ErP after
running for the period speci-
fied by timer y03
2: Retry during the period
specified by timer y03. If the
retry fails trip with alarm ErP. If
it succeeds continue to run.
3: Continue to run
1
1: Trip with alarm ErP after
deceleration stop
13: Free run stop
14: Deceleration stop
0
Availa-
ble
-
page
8-5
y13
RS-485 Error Detec-
tion Timer
0.0 to 60.0 s
2
Availa-
ble
s
page
8-5
4 Parameter List
4-159
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-11 Parameter y (RS-485 Communication Settings)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
