Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
d256
Positioning Data 7
(MSB)
−268435455 to 268435455
(MSB: -4,096 to 4,095, LSB: 0
to 65,535)
0
Availa-
ble
-
page
6-49
d257
Positioning Data 7
(LSB)
−268435455 to 268435455
(MSB: -4,096 to 4,095, LSB: 0
to 65,535)
0
Availa-
ble
-
page
6-49
d258
Positioning Data 8
(MSB)
−268435455 to 268435455
(MSB: -4,096 to 4,095, LSB: 0
to 65,535)
0
Availa-
ble
-
page
6-49
d259
Positioning Data 8
(LSB)
−268435455 to 268435455
(MSB: -4,096 to 4,095, LSB: 0
to 65,535)
0
Availa-
ble
-
page
6-49
d277
Positioning Data Set-
ting Selection via com-
munication
0: Disable Communications
Positioning Data (S20, S21)
1: Enable Communications
Positioning Data (S20, S21)
0
Availa-
ble
-
page
6-49
d278
Restarting Positioning
Range Setting
0: Disable
1～9999
0
Availa-
ble
-
page
6-58
d280
Over Travel Forced
Stop Operation Selec-
tion
0: Servo lock after decelera-
tion stop
1: Er6 fault occurs after decel-
eration stop
0
Availa-
ble
-
page
6-43
d296
Current Reference Po-
sition Monitor (MSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
page
6-57
4 Parameter List
4-158
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
