Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
A63 2nd Stop Frequency
0.0 to 60.0 Hz
999: According to F025
32767
Availa-
ble
Hz
page
7-1
14
A64
2nd Stop Frequency
Detection Method Se-
lection
0: Detected speed
1: Reference speed
100: According to F38
100 - -
page
7-114
A65
2nd Stop Frequency
Holding Time
0.00 to 10.00 s
0.00
Availa-
ble
s
page
7-114
4-2-7
Parameter b (Speed Control 3)
Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
b43
Speed Control 3
Speed Command Fil-
ter
0.000 to 5.000 s
0.02
Availa-
ble
s
page
6-26
b44
Speed Control 3
Speed Detection Filter
0.000 to 0.100 s
0.005
Availa-
ble
s
page
6-26
b45
Speed Control 3 P
Proportional Gain
0.1 to 200.0
10
Availa-
ble
-
page
6-26
b46
Speed Control 3 I Inte-
gral Time
0.001 to 9.999 s
999: Disable
0.1
Availa-
ble
s
page
6-26
b47
Speed Control 3 FF
Gain
0.00 to 99.99 s
0
Availa-
ble
s
page
6-26
b48
Speed Control 3 Out-
put Filter
0.000 to 0.100 s
0.002
Availa-
ble
s
page
6-26
b49
Speed Control 3 Notch
Filter Resonance Fre-
quency
1 to 500 Hz
200
Availa-
ble
Hz
page
6-26
4 Parameter List
4-141
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-7 Parameter b (Speed Control 3)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
