Parameter
No.
Function name Monitor or data range
Default
data
Setting
during
RUN
Unit
M89 Light Alarm Factor 3rd Last
0 (0x00 Hex): No alarm
17 (0x11 Hex): OH1 Heat sink
overheat
18 (0x12 Hex): OH2 External
alarm input
19 (0x13 Hex): OH3 Inverter
internal overheat
22 (0x16 Hex): dbH Braking
resistor overheat
23 (0x17 Hex): OL1 Motor 1
overload
24 (0x18 Hex): OL2 Motor 2
overload
34 (0x22 Hex): Er4 Option
card communications error
35 (0x23 Hex): Er5 Option
card error
47 (0x2F Hex): ErE Following
error (excessive speed devia-
tion)
53 (0x35 Hex): ErP RS-485
communications error (Option
card)
56 (0x38 Hex): Ero Position
control error
58 (0x3A Hex): CoF PID feed-
back disconnection detected
100 (0x64 Hex): FAL Detect
DC fan lock
101 (0x65 Hex): OL Motor
overload early warning
102 (0x66 Hex): OH Heat sink
overheat early warning
103 (0x67 Hex): LiF Lifetime
alarm
104 (0x68 Hex): rEF Refer-
ence loss
105 (0x69 Hex): Pid PID alarm
106 (0x6A Hex): UTL Low out-
put torque detection
107 (0x6B Hex): PTC PTC
thermistor activated
108 (0x6C Hex): rTE Inverter
life (Cumulative run time)
109 (0x6D Hex): CnT (Inverter
life, Number of startups)
0
- -
4 Parameter List
4-25
M1 Series Standard Type User's Manual (I669)
4-1 List of Monitors by Group
4
4-1-1 Parameter M (Monitor 1)
