Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit
Z58
Third Last Alarm Info. Main Circuit
DC V
oltage
0.0 to 1,000.0 V
0.0 - V
Z59
Third Last Alarm Info. Internal Air
Temperature
-32768 to 32767
0 - degC
Z60
Third Last Alarm Info. Heat Sink
Temperature
-32,768 to 32,767
0 - degC
Z61
Third Last Alarm Info. Input Termi-
nal
Bit15: ---
Bit14: ---
Bit13: ---
Bit12: EN2
Bit11: EN1
Bit10: ---
Bit9: ---
Bit8: ---
Bit7: ---
Bit6: DI5
Bit5: DI4
Bit4: DI3
Bit3: DI2
Bit2: DI1
Bit1: DI7
Bit0: DI6
0 -
-
Z62
Third Last Alarm Info. Output Ter-
minal
Bit15: ---
Bit14: ---
Bit13: ---
Bit12: ---
Bit11: ---
Bit10: ---
Bit9: ---
Bit8: RO
Bit7: ---
Bit6: ---
Bit5: ---
Bit4: ---
Bit3: ---
Bit2: ---
Bit1: DO2
Bit0: DO1
0 - -
4 Parameter List
4-47
M1 Series Standard Type User's Manual (I669)
4-1 List of Monitors by Group
4
4-1-3 Parameter z (Alarm Information 1)
