Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
C26
Pattern Operation
Stage 5 Operation
Setting
Bit 15:
0 = Forward
1 = Reverse
Bit 14: Fixed to 0 (Not used)
Bit 13 to 12: Acceleration/
Deceleration time selection
0: 1st Acceleration Time
1(F007)/1st Deceleration Time
1(F008)
1: 2nd Acceleration T
ime
1(E010)/2nd Deceleration
Time 1(E011)
2: 1st Acceleration Time
2(E012)/1st Deceleration Time
2(E013)
3: 2nd Acceleration Time
2(E014)/2nd Deceleration
Time 2(E015)
Bit 11 to 10: Minimum unit of
operation time
0: 0.01
1: 0.1
2: 1
3: 10
Bit 9 to 0: Data part of opera-
tion time
0000 to 03E7 hex (0.00 to
9.99) if Minimum unit is 0: 0.01
0064 to 03E7 hex (10.0 to
99.9) if Minimum unit is 1:
0.1
*1
0064 to 03E7 hex (100 to 999)
if Minimum unit is 2: 1
*1
0064 to 0258 hex (1,000 to
6,000) if Minimum unit is 3:
10
*2
*1. 0000 to 0063 hex and
03E8 to 03FF hex cannot be
set.
*2. 0000 to 0063 hex and 0259
to 03FF hex cannot be set.
0
Availa-
ble
-
page
5-27
4 Parameter List
4-106
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
