Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
J11
PID Control Select
W
arning Output Selec-
tion
0: Warning from absolute val-
ue
1: Warning from absolute val-
ue with hold
2: Warning from absolute val-
ue with latch
3: W
arning from absolute val-
ue with hold and latch
4: Warning from PID error
5: Warning from PID error with
hold
6: Warning from PID error with
latch
7: Warning from PID error with
hold and latch
0
Availa-
ble
-
page
7-123
J12
PID Control Upper
Limit of Warning (AH)
-100 % to 100 %
100
Availa-
ble
%
page
7-123
J13
PID Control Lower
Limit of Warning (AL)
-100 % to 100 %
0
Availa-
ble
%
page
7-123
J15
PID Control Sleep Fre-
quency for Process
Control
0.0: Disable
1.0 to 590.0 Hz
0
Availa-
ble
Hz
page
7-123
J16
PID Control Sleep
Timer for Process
Control
0 to 60 s
30
Availa-
ble
s
page
7-123
J17
PID Control Restart
Frequency after Stop-
ping for Process Con-
trol
0.0 to 590.0 Hz
0
Availa-
ble
Hz
page
7-123
J18
PID Control PID Out-
put Upper Limit
-150 to 150 %
999: Depends on setting of
F15
32767
Availa-
ble
%
page
7-123
J19
PID Control PID Out-
put Lower Limit
-150 to 150 %
999: Depends on setting of
F16
32767
Availa-
ble
%
page
7-123
4 Parameter List
4-144
M1 Series Standard Type User's Manual (I669)
