Page #448 background image
Parameter
No.
Function name Data Default data Unit
E01 to E05
E98
E99
Input Terminal [DI1] Function
Selection to Input Terminal
[DI7] Function Selection
135 (1135):
Increment/absolute position
switching “INC/ABS”
144 (1
144):
Position change command
“POS-SET”
145 (1145):
Position command selection 1
“CP1”
146 (1146):
Position command selection 2
“CP2”
147 (1147):
Position command selection 3
“CP3”
- -
d237 Positioning Data Type
0: Absolute position (ABS)
1: Relative position (INC)
0 -
d238
Position Data Determination
Time
0.000 to 0.100 s 0.000 s
d277
Positioning Data Setting Se-
lection via communication
0: Disable Communications
Positioning Data (S20, S21)
1: Enable Communications
Positioning Data (S20, S21)
0 -
S20
Positioning Data via Commu-
nication (MSB)
−268435455 to 268435455
(MSB: -4096 to 4095)
0 -
S21
Positioning Data via Commu-
nication (LSB)
(LSB: 0 to 65535) 0 -
Positioning Data Type (d237)
Handling of the positioning data set to positioning data 1 to 8 can be switched between handling as
absolute positions or as moving amounts.
To switch handling when necessary, use increment/absolute position switching “INC/ABS” (data =
135) in the multifunction input terminal function.
When “INC/ABS” is allocated to multifunction input terminals, the d237 setting is disabled.
Position Data Determination T
ime (d238)
When position command selection 1 “CP1” to position command selection 3 “CP3” is switched,
chattering may cause the selected positioning data to change. In cases like these, set the time up
to settling of the positioning data to d238.
Positioning Data Setting Selection via communication (d277)
Positioning data can also be assigned via communication. To assign positioning data via communi-
cation, set 1 to d277. The upper four digits and lower four digits of the positioning data are as-
signed to Positioning Data via Communication (MSB) (S20) and Positioning Data via Communica-
tion (LSB) (S21), respectively.
To reflect positioning data, turn the position change command “POS-SET” ON.
While commands via communication are enabled, Positioning Data 1 (MSB) (d244) and Positioning
Data 1 (LSB) (d245) are switched to S20 and S21. These parameters can also be switched to posi-
tioning data 2 to 8 by position command selection 1 “CP1” to position command selection 3 “CP1.”
6 Vector Control and Applied Functions
6-42
M1 Series Standard Type User's Manual (I669)
