Page #713 background image
Parameter
No.
MODBUS ad-
dress (MSB)
MODBUS ad-
dress (LSB)
Parameter name
Communica-
tion data for-
mat (during
single-word
access)
Communica-
tion data for-
mat (during
double-word
access)
H350 3633h -
Recipient Register of All Sta-
tions in Co-inverter Communi-
cation 4
1 -
H351 3634h -
Sender Register of All Sta-
tions in Co-inverter Communi-
cation 4
1 -
H352 3635h -
Recipient Station Number of
All Stations in Co-inverter
Communication 5
1 -
H353 3636h -
Recipient Register of All Sta-
tions in Co-inverter Communi-
cation 5
1 -
H354 3637h -
Sender Register of All Sta-
tions in Co-inverter Communi-
cation 5
1 -
H355 3638h -
Modbus Mapping Function
Selection
1 -
H356 3639h -
Modbus Mapping 1 External
Register
1 -
H357 363Ah -
Modbus Mapping 2 External
Register
1 -
H358 363Bh -
Modbus Mapping 3 External
Register
1 -
H359 363Ch -
Modbus Mapping 4 External
Register
1 -
H360 363Dh -
Modbus Mapping 5 External
Register
1 -
H361 363Eh -
Modbus Mapping 6 External
Register
1 -
H362 363Fh -
Modbus Mapping 7 External
Register
1 -
H363 3640h -
Modbus Mapping 8 External
Register
1 -
H364 3641h -
Modbus Mapping 9 External
Register
1 -
H365 3642h -
Modbus Mapping 10 External
Register
1 -
H366 3643h -
Modbus Mapping 1 External
Register Sign
1 -
H367 3644h -
Modbus Mapping 2 External
Register Sign
1 -
H368 3645h -
Modbus Mapping 3 External
Register Sign
1 -
H369 3646h -
Modbus Mapping 4 External
Register Sign
1 -
H370 3647h -
Modbus Mapping 5 External
Register Sign
1 -
8 Communications Functions
8-63
M1 Series Standard Type User's Manual (I669)
8-9 Modbus Communication Data Lists
