Parameter
No.
MODBUS ad-
dress (MSB)
MODBUS ad-
dress (LSB)
Parameter name
Communica-
tion data for-
mat (during
single-word
access)
Communica-
tion data for-
mat (during
double-word
access)
W43 5271h -
Communications Control Out-
put Signal Monitor
15 -
W44 5272h -
Input Terminal [AI1] Input Volt-
age
4 -
W45 5273h -
Input Terminal [AI2]AII Input
Current (AII)
4 -
W46 5274h -
Output Terminal [AO]AOV
Output V
oltage
4 -
W48 5276h -
Output Terminal [AO]PO Out-
put Frequency
1 -
W49 5277h -
Input Terminal [AI2] Input Volt-
age (AIV)
4 -
W50 5278h -
Terminal [AO](AOI) output
current
3 -
W55 527Dh -
Pulse Input (A/B Phase [PIA]
[PIB])
6 -
W56 527Eh - Pulse Input (Z Phase [PIZ]) 1 -
W57 527Fh - Reserved 73 -
W58 5280h - Reserved 1 -
W59 5281h - Reserved 73 -
W60 5282h - Reserved 1 -
W61 5283h - Reserved 73 -
W62 5284h - Reserved 1 -
W63 5285h - Reserved 1 -
W66 5288h - Reserved 4 -
W67 5289h -
Cumulative Run Time of Ca-
pacitors on Printed Circuit
Boards
74 -
W68 528Ah -
Cumulative Run Time of Cool-
ing Fan
74 -
W70 528Ch 528Dh Total Power ON Time Monitor 1 1
W71 1025h -
Main circuit DC voltage Moni-
tor
3 -
W72 528Fh -
Internal Air Highest Tempera-
ture
2 -
W73 5290h -
Heat Sink Maximum Tempera-
ture
2 -
W74 5291h -
Maximum Effective Current
V
alue
19 -
W75 5292h -
Main Circuit Capacitor's Ca-
pacitor Monitor
3 -
W76
1016h 1017h
Cumulative Run Time of Elec-
trolytic Capacitors on PC
Board
1 1
W77 5295h 5296h
Cumulative Run Time of Cool-
ing Fan
1 1
8 Communications Functions
8-79
M1 Series Standard Type User's Manual (I669)
8-9 Modbus Communication Data Lists
8
8-9-2 Register List
