Parameter

No.

MODBUS ad-

dress (MSB)

MODBUS ad-

dress (LSB)

Parameter name

Communica-

tion data for-

mat (during

single-word

access)

Communica-

tion data for-

mat (during

double-word

access)

X37 5567h -

Latest Alarm Info. Speed De-

tection

29 -

X38 5568h -

Latest Alarm Info. Running

Status 3

44 -

X49 5573h - Fault Counter 1 -

X60 001Dh 001Eh

Last Info. Alarm Info. Output

Frequency

22 5

X61 001Fh -

Last Alarm Info. Output Cur-

rent

19 -

X62 5581h -

Last Alarm Info. Output Volt-

age

1 -

X63 5582h -

Last Alarm Info. Torque Moni-

tor

2 -

X64 5583h 5584h

Last Alarm Info. Frequency

Command

22 5

X65 001Ch -

Last Alarm Info. Running Sta-

tus

16 -

X66 0023h 0024h

Last Alarm Info. Cumulative

Ope. T

ime

1 1

X67 5587h -

Last Alarm Info. Number of

Startups

1 -

X68

0020h -

Last Alarm Info. Main Circuit

DC Voltage

3 -

X69 5589h -

Last Alarm Info Internal Air

Temperature

2 -

X70 558Ah -

Last Alarm Info. Heat Sink

Temperature

2 -

X71 558Bh -

Last Alarm Info. Input T

ermi-

nal

43 -

X72 558Ch -

Last Alarm Info. Output Termi-

nal

15 -

X73 558Dh -

Last Alarm Info. Input Termi-

nal via Communication

14 -

X74 558Eh -

Last Alarm Info. Output Termi-

nal via Communication

15 -

X76 5590h -

Last Alarm Info. Running Sta-

tus 2

76 -

X77 5591h -

Last Alarm Info. Speed Detec-

tion

29 -

X78 5592h -

Last Alarm Info. Running Sta-

tus 3

44 -

X97 55A5h -

Input Input Terminal [PTC] In-

put V

oltage

4 -

X108 0017h

0018h

Latest Alarm Info. Cumulative

Running Time

1 1

X118

0021h 0022h

Last Alarm Info. Cumulative

Running Time

1 1

8 Communications Functions

8-83

M1 Series Standard Type User's Manual (I669)

8-9 Modbus Communication Data Lists

8-9-2 Register List
