Parameter

No.

MODBUS ad-

dress (MSB)

MODBUS ad-

dress (LSB)

Parameter name

Communica-

tion data for-

mat (during

single-word

access)

Communica-

tion data for-

mat (during

double-word

access)

Z07 578Ah -

Second Last Alarm Info. Num-

ber of Startups

1 -

Z08 002Ah -

Second Last Alarm Info. Main

Circuit DC V

oltage

3 -

Z09 578Ch -

Second Last Alarm Info. Inter-

nal Air Temperature

2 -

Z10 578Dh -

Second Last Alarm Info. Heat

Sink Temperature

2 -

Z11 578Eh -

Second Last Alarm Info. Input

Terminal

43 -

Z12 578Fh -

Second Last Alarm Info. Out-

put Terminal

15 -

Z13 5790h -

Second Last Alarm Info. Input

Terminal via Communication

14 -

Z14 5791h -

Second Last Alarm Info. Out-

put Terminal via Communica-

tion

15 -

Z16 5793h -

Second Last Alarm Info. Run-

ning Status 2

76 -

Z17

5794h -

Second Last Alarm Info.

Speed Detection

29 -

Z18 5795h -

Second Last Alarm Info. Run-

ning Status 3

44 -

Z40 57ADh - 1st Cumulative Run Time 74 -

Z41 57AEh -

2nd Cumulative Run Time of

motor

74 -

Z44 57AFh - 2nd Number of Startups 1 -

Z50 0031h 0032h

Third Last Alarm Info. Output

Frequency

22 5

Z51 0033h -

Third Last Alarm Info. Output

Current

19 -

Z52 57B8h -

Third Last Alarm Info. Output

oltage

1 -

Z53 57B9h -

Third Last Alarm Info. T

orque

Monitor

2 -

Z54 57BAh 57BBh

Third Last Alarm Info. Fre-

quency Command

22 5

Z55 0030h -

Third Last Alarm Info. Run-

ning Status

16 -

Z56 0037h 0038h

Third Last Alarm Info. Cumu-

lative Ope. T

ime

1 1

Z57 57BFh -

Third Last Alarm Info. Number

of Startups

1 -

Z58

0034h -

Third Last Alarm Info. Main

Circuit DC Voltage

3 -

Z59 57C1h -

Third Last Alarm Info. Internal

Air Temperature

2 -

8 Communications Functions

8-85

M1 Series Standard Type User's Manual (I669)

8-9 Modbus Communication Data Lists

8-9-2 Register List
