3G3M1-A2055/A2075/A2110/A2150/A2185
6 11
16
1
100
120
80
60
40
20
0
Output current derating [%]
Carrier frequency [kHz]

3G3M1-A4004/A4007/A4015/A4030/A4040/AB037
6 11
16
1
100
120
80
60
40
20
0
Output current derating [%]
Carrier frequency [kHz]
ND
HD
50°C HND(*1)
HND/HHD
*1. When using 3G3M1-A4040 at 50°C.
Appendix
A-3
M1 Series Standard Type User's Manual (I669)
A-1 Derating Table
