Omron M1 Series User Manual

Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire
size [mm2]
Inverter ground (G)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
60°C 75°C 90°C
3G3M1-AB001 - 0.1 2.0 2.0 2.0
- 3G3M1-AB001 0.2 2.0 2.0 2.0
3G3M1-AB002 - 2.0 2.0 2.0
- 3G3M1-AB002 0.4 2.0 2.0 2.0
3G3M1-AB004 - 2.0 2.0 2.0
- 3G3M1-AB004 0.55 2.0 2.0 2.0
3G3M1-AB007 - 0.75 2.0 2.0 2.0
- 3G3M1-AB007 1.1 2.0 2.0 2.0
3G3M1-AB015 - 1.5 2.0 2.0 2.0
- 3G3M1-AB015 2.2 2.0 2.0 2.0
3G3M1-AB022 - 2.0 2.0 2.0
- 3G3M1-AB022 3 2.0 2.0 2.0
3G3M1-AB037 - 3.7 3.5 3.5 3.5

Three-phase 200-V class (Panel internal temperature 40°C or less)
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Main power supply input (L1/R, L2/S, L3/T)
When DC reactor (DCR) is
used
Without DC reactor
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-A2001 - 0.1 2.0 2.0 2.0 0.6 2.0 2.0 2.0 1.1
3G3M1-A2002 3G3M1-A2001 0.2 2.0 2.0 2.0 0.9 2.0 2.0 2.0 1.8
- 3G3M1-A2002 0.4 2.0 2.0 2.0 1.6 2.0 2.0 2.0 2.6
3G3M1-A2004 - 2.0 2.0 2.0 1.6 2.0 2.0 2.0 3.1
- 3G3M1-A2004 0.75 2.0 2.0 2.0 3.0 2.0 2.0 2.0 4.9
3G3M1-A2007 - 2.0 2.0 2.0 3.0 2.0 2.0 2.0 5.3
- 3G3M1-A2007 1.1 2.0 2.0 2.0 4.3 2.0 2.0 2.0 6.7
3G3M1-A2015 - 1.5 2.0 2.0 2.0 5.7 2.0 2.0 2.0 9.5
- 3G3M1-A2015 2.2 2.0 2.0 2.0 8.3 2.0 2.0 2.0 12.8
3G3M1-A2022 - 2.0 2.0 2.0 8.3 2.0 2.0 2.0 13.2
- 3G3M1-A2022 3 2.0 2.0 2.0 11.7 2.0 2.0 2.0 17.9
3G3M1-A2037 - 3.7 2.0 2.0 2.0 14.0 3.5 2.0 2.0 22.2
- 3G3M1-A2037 5.5 2.0 2.0 2.0 19.9 3.5 2.0 2.0 28.5
3G3M1-A2055 - 2.0 2.0 2.0 21.1 5.5 3.5 2.0 31.5
3G3M1-A2075 3G3M1-A2055 7.5 3.5 2.0 2.0 28.8 8.0 5.5 3.5 42.7
3G3M1-A2110 3G3M1-A2075 11 8.0 5.5 3.5 42.2 14.0 8.0 5.5 60.7
3G3M1-A2150 3G3M1-A2110 15 14.0 8.0 5.5 57.6 22.0 14.0 14.0 80.0
2 Design
2-28
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
