Precautions for Safe Use
22
NJ-series CPU Unit Software User’s Manual (W501)
Do not apply voltages or connect loads to the Output Units or slaves in excess of the maximum rat-
ings.
Surge current occurs when the power supply is turned ON. When selecting fuses or breakers for
external circuits, consider the above precaution and allow sufficient margin in shut-off performance.
Refer to the relevant manuals for surge current specifications. Refer to the NJ-series CPU Unit Hard-
ware Users Manual (Cat. No. W500) for surge current specifications.
If the full dielectric strength voltage is applied or turned OFF using the switch on the tester, the gener-
ated impulse voltage may damage the Power Supply Unit. Use the adjustment on the tester to gradu-
ally increase and decrease the voltage.
Apply the voltage between the Power Supply Unit's L1 or L2 terminal and the GR terminal when test-
ing insulation and dielectric strength.
Do not supply AC power from an inverter or other device with a square-wave output. Internal temper-
ature rise may result in smoking or burning. Always input a sinusoidal wave with the frequency that is
given in the NJ-series CPU Unit Hardware User’s Manual (Cat. No. W500).
Install external breakers and take other safety measures against short-circuiting in external wiring.
It takes up to approximately 10 to 20 s to enter RUN mode after the power is turned ON. The outputs
during this time behave according to the slave or Unit specifications. Use the RUN output on the
Power Supply Unit, for example, to implement fail-safe circuits so that external devices do not operate
incorrectly.
Configure the external circuits so that the power supply to the control system turns ON only after the
power supply to the Controller has turned ON. If the power supply to the Controller is turned ON after
the control power supply, temporary errors may result in incorrect control system signals because the
output terminals on Output Units may momentarily turn ON when power supply is turned ON to the
Controller.
If you transfer data from a backup file on an SD Memory Card to the Controller when the power sup-
ply is turned ON, properly select the data groups to transfer. If the data for an unintended data group
is transferred to the Controller, it may cause the equipment to operate unpredictably.
Never turn OFF the power supply to the Controller until RUN mode is entered after the power is
turned ON. If the power supply is turned OFF, a Battery-backup Memory Check Error may occur at
next time you start operation. If a Battery-backup Memory Check Error occurs, the variables retained
are set to their initial values and the Holding, DM and EM Areas in memory used for CJ-series Units
are cleared to all zeros. If you want to resume the operation, reload the correct data for the variables
retained and CJ-series Unit memory, as required.
Never turn OFF the power supply to the Controller when the BUSY indicator is flashing. While the
BUSY indicator is lit, the user program and settings in the CPU Unit are being backed up in the built-
in non-volatile memory. This data will not be backed up correctly if the power supply is turned OFF.
Also, a major fault level Controller error will occur the next time you start operation, and operation will
stop.
Do not turn OFF the power supply or remove the SD Memory Card while SD Memory Card access is
in progress (i.e., while the SD BUSY indicator flashes). Data may become corrupted, and the Control-
ler will not operate correctly if it uses corrupted data. To remove the SD Memory Card from the CPU
Unit while the power supply is ON, press the SD Memory Card power supply switch and wait for the
SD BUSY indicator to turn OFF before you remove the SD Memory Card.
Do not disconnect the cable or turn OFF the power supply to the Controller when downloading data
or the user program from Support Software.
Always turn OFF the power supply to the Controller before you attempt any of the following.
Mounting or removing I/O Units or the CPU Unit
Assembling the Units
Turning ON the Power Supply
Turning OFF the Power Supply
