9-45
9 Backup Functions
NJ-series CPU Unit Software User’s Manual (W501)
9-11 Backup-related Files
9
9-11-2 Specifications of a Backup File
This section describes the file name, creation timing, and created directory for a backup file.
*1 A CPU Unit with unit version 1.08 or later and Sysmac Studio version 1.09 or higher are required.
This section describes the file name, creation timing, created directory, and data group specification
method for a restore command file.
9-11-2 Specifications of a Backup File
File Name
File File name
Backup file NJBackup.dat
File Creation Timing and Created Directories
Function Procedure Creation timing Created directory
SD Memory
Card backups
CPU Unit front-panel DIP
switch
When backup is exe-
cuted
Root directory on the SD Memory
Card
System-defined variables When backup is exe-
cuted
Directory on the SD Memory Card
that you specified with the system-
defined variable
SD Memory Card Dialog Box
in Sysmac Studio
When backup is exe-
cuted
Directory on the SD Memory Card
that you specified with the Sysmac
Studio
Special instruction
*1
When backup is exe-
cuted
The directory on the SD Memory
Card that you specified for the
input variable of the Backup-
ToMemoryCard instruction
Sysmac Studio
Controller
backups
Sysmac Studio Controller
Backup Dialog Box
When backup is exe-
cuted
Directory in the computer that you
specified with the Sysmac Studio
Importing and
exporting Sys-
mac Studio
backup file data
Sysmac Studio Backup File
Export Dialog Box
When data is
exported
Directory in the computer that you
specified with the Sysmac Studio
9-11-3 Specifications of a Restore Command File
File Name
File File name
Restore command file RestoreCommand.ini
