3-9
3 I/O Ports, Slave Configuration, and Unit Configuration
NJ-series CPU Unit Software User’s Manual (W501)
3-3 I/O Ports and Device Variables
3
3-3-2 I/O Port Names
The I/O port names are registered automatically. The I/O port names differ as given below depending
on whether the device (i.e., Unit or slave) is an EtherCAT slave, CJ-series Basic I/O Unit, or CJ-series
Special Unit.
The following I/O port names are used for Remote I/O Terminals that are EtherCAT slave devices.
Example for a 16-point Remote I/O Terminal: Bit00 to Bit15
For other slaves, all or part of the object names that are defined in the EtherCAT object dictionary are
used.
Example for Analog Input Unit: CH0_input16-bit
Examples for the R88D-KN50H-ECT: Position actual value and Digital inputs
If the device is a CJ-series Basic I/O Unit, I/O port names are created according to the following rules.
 Rules for I/O Port Names for Basic I/O Units
3-3-2 I/O Port Names
EtherCAT Slave Devices
CJ-series Basic I/O Unit Devices
Inputs Outputs
Ch  _In 
16-bit words: 1 to 4
Terminal number: 00 to 15
Ch  _Out 
16-bit words: 1 to 4
Terminal number: 00 to 15

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
