9 Backup Functions
9-8
NJ-series CPU Unit Software User’s Manual (W501)
The Sysmac Studio Controller backup functions are used to back up, restore, and compare data on the
computer. Importing and exporting Sysmac Studio backup file data are used to save and read different
types of data between the Sysmac Studio projects and backup files on the computer without using a
Controller. The Sysmac Studio variable and memory backup functions are used to back up battery-
backup present values to the computer and restore them from the computer.
Version Information
A CPU Unit with unit version 1.03 or later and Sysmac Studio version 1.04 or higher are required
to use the following backup functions: SD Memory Card backups, automatic transfers from SD
Memory Cards, Sysmac Studio Controller backups, and importing and exporting Sysmac Studio
backup file data.
Functions That Save Data to the Computer
Function name Description
Operating method
Reference
CPU Unit
front-panel
DIP switch
System-
defined
variables
Sysmac
Studio
Sysmac Stu-
dio Control-
ler backups
Backing
up data
The Controller data is
saved in a backup file on
the computer.

9-5-1
Backup
(Controller to
Computer)
Restor-
ing data
The data in a backup file
on the computer is trans-
ferred to the Controller.

9-5-2
Restore
(Computer
to Controller)
Verifying
data
The Controller data and
the data in a backup file on
the computer are com-
pared.

9-5-3 Verify
(between
Controller
and Com-
puter)
Importing
and exporting
Sysmac Stu-
dio backup
file data
Export-
ing data
The data is exported from
the project on the Sysmac
Studio to a backup file
without using a Controller.

9-6 Import-
ing and
Exporting
Sysmac Stu-
dio Backup
File Data
Import-
ing data
The data in the backup file
is imported into the Sys-
mac Studio project without
using a Controller.

Sysmac Stu-
dio variable
and memory
backup func-
tions
Backing
up data
You can back up the pres-
ent values of data that is
backed up by a battery to
an XML file on the com-
puter.

9-7 Sysmac
Studio Vari-
able and
Memory
Backup
Functions
Restor-
ing data
You can restore the pres-
ent values of data that is
backed up by a battery
from the computer to the
CPU Unit.


Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
