12-2 Troubleshooting
12
12-2-4 Error Descriptions
* This event code was added for unit version 1.03 of the CPU Unit.
* This event code was added for unit version 1.05 of the CPU Unit.
Event name Safe Mode Event code 40170000 hex*
Meaning The CPU Unit started in Safe Mode.
Source PLC Function Module Source details None Detection
timing
At power ON or
Controller reset
Error attributes Level Observation Recovery --- Log category System
Effects User program Stops. Operation ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The power supply was turned ON to
the Controller when the Safe Mode
was set on the DIP switch on the CPU
Unit.
--- ---
Attached
information
None
Precautions/
Remarks
If the Controller is started when the CPU Unit is in Safe Mode, the CPU Unit will start in PROGRAM mode even if the
startup mode is set to RUN mode.
Event name NX Message Communications Error Event code 80230000 hex*
Meaning An error has occurred in message communications.
Source
PLC Function Module,
EtherCAT Master Function Module,
or EtherNet/IP Function Module
Source details None Detection
timing
During NX mes-
sage communi-
cations
Error attributes Level Observation Recovery --- Log category System
Effects User program Continues. Operation ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The communications cable is broken. Check the communications cable and
replace it if it is broken.
Check the communications cable to
see if it is operating properly.
Attached
information
The communications cable connec-
tor is disconnected.
Reconnect the connector and make
sure it is mated correctly.
Make sure the communications cable
is connected properly.
The NX message communications
load is high.
Reduce the number of times that
instructions are used to send NX
messages. Or, increase the value of
the TimeOut input variable to the
instruction. If more than one copy of
the Sysmac Studio is connected,
reduce the frequency of simultaneous
operations.
Reduce the number of times that
instructions are used to send NX
messages. Or, increase the value of
the TimeOut input variable to the
instruction. If more than one copy of
the Sysmac Studio is connected,
reduce the frequency of simultaneous
operations.
Precautions/
Remarks
Attached Information 1: System Information
Attached Information 2: Type of Communications
0: NX bus
1: EtherCAT
65,535: Unit internal communications (routing)
