This section gives the I/O refresh times for CJ-series Units.
Basic I/O Units
The following table gives the I/O refresh times for Basic I/O Units that are used on the CPU Rack.
The I/O refresh times for these Units on Expansion Racks are approx. 1.5 times the values that are
given in the table.
Special I/O Units
The following table gives the I/O refresh times for Special I/O Units that are used on the CPU Rack.
The I/O refresh times for these Units on Expansion Racks are approx. 1.5 times the values that are
given in the table.
I/O Refresh Times for CJ-series Units
Unit name Model numbers
I/O refresh time per Unit
[s]
8/16-point DC Input Units CJ1W-ID201/211/212 1
32-point DC Input Units CJ1W-ID231/232/233 2
64-point DC Input Units CJ1W-ID261/262 4
8/16-point AC Input Units CJ1W-IA201/111 1
16-point Interrupt Input Unit CJ1W-INT01 1
16-point Quick-response Input
Unit
CJ1W-IDP01 1
Relay Contact Output Units CJ1W-OC201/211 1
Triac Output Unit CJ1W-OA201 1
8/16-point Transistor Output
Units
CJ1W-OD201/202/203/204//211/212/213 1
32-point Transistor Output
Units
CJ1W-OD231/232/233/234 2
64-point Transistor Output
Units
CJ1W-OD261/262/263 4
24-VDC Input/Transistor Output
Units (16 inputs/16 outputs)
CJ1W-MD231/232/233 1
24-VDC Input/Transistor Output
Units (32 inputs/32 outputs)
CJ1W-MD261/263 2
TTL I/O Unit CJ1W-MD563 4
B7A Interface Units
CJ1W-B7A04 4
CJ1W-B7A14 4
CJ1W-B7A22 4
Unit name Model numbers
I/O refresh time per Unit
[s]
Isolated-type Units with Uni-
versal Inputs
CJ1W-AD04U 66
Analog Input Units CJ1W-AD041-V1/081-V1/042 24
Analog Output Units CJ1W-DA021/041/042V/08V/08C 24
Analog I/O Units CJ1W-MAD42 24
Isolated-type Units with Uni-
versal Inputs
CJ1W-PH41U
80 (180)
*1
Isolated-type DC Input Unit
CJ1W-PDC15
60 (100)
*1
Temperature Control Units CJ1W-TC 114
ID Sensor Units
CJ1W-V680C11 76
CJ1W-V680C12 86
High-speed Counter Unit CJ1W-CT021 54
