Page #569 background image
Appendices
A-42
NJ-series CPU Unit Software User’s Manual (W501)
_EIP_CipErr CIP Communica-
tions Error
This is the error status variable for CIP com-
munications.
It represents the following error flags.
_EIP_IdentityErr (Identity Error)
_EIP_TDLinkCfgErr (Tag Data Link Setting
Error)
_EIP_TDLinkOpnErr (Tag Data Link Con-
nection Failed)
_EIP_TDLinkErr (Tag Data Link Communi-
cations Error)
_EIP_TagAdrErr (Tag Name Resolution
Error)
_EIP_MultiSwONErr (Multiple Switches ON
Error)
Note If a Tag Resolution Error occurs, it is
recorded in the event log and this vari-
able changes to TRUE. Refer to infor-
mation on the meanings of the error
status bits at the end of this appendix
for details.
WORD 16#0000 to
16#00F0
page A-74
_EIP_TcpAppErr TCP
Application Com-
munications Error
This is the error status variable for TCP appli-
cation communications.
It represents the following error flags.
_EIP_TopAppCfgErr (TCP/IP Setting Error)
_EIP_NTPSrvErr (NTP Server Connection
Error)
_EIP_DNSSrvErr (DNS Server Connection
Error)
Note Refer to information on the meanings of
the error status bits at the end of this
appendix for details.
WORD 16#0000 to
16#00F0
page A-74
_EIP_MacAdrErr MAC Address
Error
Indicates that an error occurred when the
MAC address was read at startup.
TRUE: Error
FALSE: Normal
BOOL TRUE or
FALSE
page A-74
_EIP_LanHwErr Communications
Controller Error
TRUE: The communications controller failed.
FALSE: Normal
BOOL TRUE or
FALSE
page A-74
_EIP_EtnCfgErr Basic Ethernet
Setting Error
TRUE: The Ethernet communications speed
setting (Speed/Duplex) is incorrect. Or, a read
operation failed.
FALSE: Normal
BOOL TRUE or
FALSE
page A-75
_EIP_IPAdrCfgErr TCP/IP Basic
Setting Error
TRUE:
There is an illegal IP address setting.
A read operation failed.
The IP address obtained from the BOOTP
server is inconsistent.
The DNS settings are not correct.
FALSE: Normal
BOOL TRUE or
FALSE
page A-75
_EIP_IPAdrDupErr IP Address Dupli-
cat
ion Error
TRUE: The same IP address is assigned to
more than one nod
e.
FALSE: Other than the above.
BOOL TRUE or
FALSE
page A-75
_EIP_BootpErr BOOTP Server
Error
TRUE: There was a failure to connect to the
BOOTP server (timeout).
FALSE: The BOOTP is not enabled, or
BOOTP is enabled and an IP address was
normally obtained from the BOOTP server.
BOOL TRUE or
FALSE
page A-75
Variable name Meaning Function Data type
Range of
values
Reference
