Appendices
A-72
NJ-series CPU Unit Software User’s Manual (W501)
* Disabled slaves are not included.
Variable name _EC_DisableSlavTbl
Meaning Disabled Slave Table Global/local Global
Function Slaves are given in the table in the order of slave node addresses.
The element for a slave is TRUE if the corresponding slave is disabled.
Data type Array [1..192] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EC_PDActive
Meaning Process Data Communications Status Global/local Global
Function TRUE when process data communications are performed with all slaves*.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
Disconnect EtherCAT Slave
EC_DisconnectSlave
Connect EtherCAT Slave
EC_ConnectSlave
Variable name _EC_PktMonStop
Meaning Packet Monitoring Stopped Global/local Global
Function TRUE when packet monitoring is stopped.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
Stop Packet Monitor
EC_StopMon
Start Packet Monitor
EC_StartMon
Variable name _EC_LinkStatus
Meaning Link Status Global/local Global
Function TRUE if the communications controller link status is Link ON.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EC_PktSaving
Meaning Saving Packet Data File Global/local Global
Function Shows whether a packet data file is being saved.
TRUE: Packet data file being saved.
FALSE: Packet data file not being saved.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
Saving Packet Data File
EC_SaveMon
