A-75
Appendices
NJ-series CPU Unit Software User’s Manual (W501)
A-4 Specifications for Individual System-defined Variables
App
A-4-6 EtherNet/IP Function Module, Category Name: _EIP
Variable name _EIP_EtnCfgErr
Meaning Basic Ethernet Setting Error Global/local Global
Function TRUE: The Ethernet communications speed setting (Speed/Duplex) is incorrect. Or, a read operation failed.
FALSE: Normal
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EIP_IPAdrCfgErr
Meaning TCP/IP Basic Setting Error Global/local Global
Function TRUE:
There is an illegal IP address setting.
A read operation failed.
The IP address obtained from the BOOTP server is inconsistent.
The DNS settings are not correct.
FALSE: Normal
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EIP_IPAdrDupErr
Meaning IP Address Duplication Error Global/local Global
Function TRUE: The same IP address is assigned to more than one node.
FALSE: Other than the above.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EIP_BootpErr
Meaning BOOTP Server Error Global/local Global
Function TRUE: There was a failure to connect to the BOOTP server (timeout).
FALSE: The BOOTP is not enabled, or BOOTP is enabled and an IP address was normally obtained from the
BOOTP server.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EIP_IPRTblErr
Meaning TCP/IP Advanced Setting Error Global/local Global
Function TRUE: There is an error in one of the following settings. Or, a read operation failed.
IP router table settings
Hosts settings
FALSE: Normal.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
