Omron NJ Series

A-77
Appendices
NJ-series CPU Unit Software User’s Manual (W501)
A-4 Specifications for Individual System-defined Variables
App
A-4-6 EtherNet/IP Function Module, Category Name: _EIP
 Functional Classification: EtherNet/IP Communications Status
Variable name _EIP_MultiSwONErr
Meaning Multiple Switches ON Error Global/local Global
Function TRUE: More than one data link start/stop switch changed to TRUE at the same time.
FALSE: Other than the above.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EIP_TcpAppCfgErr
Meaning TCP/IP Setting Error Global/local Global
Function TRUE: At least one of the set values for a TCP/IP application (FTP, NTP, SNMP) is incorrect. Or, a read operation
failed.
FALSE: Normal.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EIP_NTPSrvErr
Meaning NTP Server Connection Error Global/local Global
Function TRUE: The NTP client failed to connect to the server (timeout).
FALSE: NTP is not set or the connection was successful.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EIP_DNSSrvErr
Meaning DNS Server Connection Error Global/local Global
Function TRUE: The DNS client failed to connect to the server (timeout).
FALSE: DNS is not enabled. Or, DNS is enabled and the connection was successful.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EIP_EtnOnlineSta
Meaning Online Global/local Global
Function TRUE: The built-in EtherNet/IP port’s communications can be used. (The link is ON and IP address is defined.
Also, there are no errors).
FALSE: The built-in EtherNet/IP port’s communications is disabled due to an error in initial processing, restart
processing, or link OFF status.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
