Appendices
A-80
NJ-series CPU Unit Software User’s Manual (W501)
Functional Classification: EtherNet/IP Communications Switches
Variable name _EIP_NTPResult Members .ExecNormal
Meaning NTP Operation Result Global/local Global
Function This variable shows if the NTP operation ended normally.
TRUE: Indicates an NTP normal end.
FALSE: Indicates that NTP operation ended in an error or has not been executed even once.
Note Do not use this variable in the user program. There may be a delay in updating it. Use this variable only to
access status through communications from an external device.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Not possible Related instruc-
tions
You can read the contents of this variable with the GetNTPStatus instruc-
tion.
Variable name _EIP_TDLinkStartCmd
Meaning Tag Data Link Communications Start Switch Global/local Global
Function Change this variable to TRUE to start tag data links.
It automatically changes back to FALSE after tag data link operation starts.
Note Do not force this switch to change to FALSE from the user program or from the Sysmac Studio. It changes
to FALSE automatically.
Data type BOOL Range of values TRUE or FALSE
R/W access RW Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
Variable name _EIP_TDLinkStopCmd
Meaning Tag Data Link Communications Stop Switch Global/local Global
Function Change this variable to TRUE to stop tag data links.
It automatically changes back to FALSE after tag data link operation stops.
Note Do not force this switch to change to FALSE from the user program or from the Sysmac Studio. It changes
to FALSE automatically.
Data type BOOL Range of values TRUE or FALSE
R/W access RW Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
---
To Next Page
